Product Summary
The LM193DR is a kind of dual differential comparator. It includes two independent voltage comparators that are designed to operate from a single power supply over a wide range of voltages. The LM193DR operation from dual supplies also is possible aslong as the difference between the two supplies is 2 V to 36 V, and VCC is at least 1.5 V more positive than the input common-mode voltage. Current drain of the LM193DR is independent of the supply voltage. The outputs can be connected to other open-collector outputs to achieve wired-AND relationships.
Parametrics
LM193DR absolute maximum ratings: (1)Supply voltage, VCC: 36 V; (2)Differential input voltage, VID: ±36 V; (3)Input voltage range, VI (either input): 0.3 V to 36 V; (4)Output voltage, VO: 36 V; (5)Output current, IO: 20 mA; (6)Duration of output short-circuit to ground: Unlimited; (7)Package thermal impedance, θJA: 97℃/W; (8)Operating virtual junction temperature, TJ: 150℃; (9)Storage temperature range, Tstg: 65℃ to 150℃.
Features
LM193DR features: (1)Single Supply or Dual Supplies; (2)Wide Range of Supply Voltage: Max Rating: 2 V to 36 V; (3)Low Supply-Current Drain Independent of Supply Voltage: 0.4 mA Typ Per Comparator; (4)Low Input Bias Current: 25 nA Typ; (5)Low Input Offset Current: 3 nA Typ; (6)Low Input Offset Voltage: 2 mV Typ; (7)Common-Mode Input Voltage Range Includes Ground; (8)Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage: ±36 V; (9)Low Output Saturation Voltage; (10)Output Compatible With TTL, MOS, and CMOS.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM193DR |
Texas Instruments |
Comparator ICs Dual Diff GP |
Data Sheet |
|
|
||||||||||||
|
LM193DRG4 |
Texas Instruments |
Comparator ICs Dual Diff Comparator |
Data Sheet |
|
|
||||||||||||
